Putzmeister SP11 LMR Stage V Mortar / Grout Pump
- Product Code: WEB-SP11LMRSV
-
Description:
This specialist machine can be used for all premixed dry mortar and site-made mixes. The Putzmeister SP11 LMR worm pump offers lasting value, thanks to its lightweight yet robust plastic hood, for example, which can withstand even the toughest conditions on site – thus making it very economical. It can be used for both exterior plaster (lime, lime cement and insulating plaster) as well as interior plaster (lime plaster). Some of the special applications for this machine are light masonry or fire protection mortar, filling and grouting work, and concrete renovation. It has a mixer capacity of 180L and the motor generates 16.3 kW of power.
PLEASE CONTACT US FOR MORE INFORMATION AND PRICING.
KEY FEATURES
• Optimal manoeuvrability thanks to low drawbar load
• Optimal soundproofing thanks to double-walled canopy
• Water metering pipe in the mixer grill prevents blockages
• Quiet 3-cylinder 16.3 kW Kubota engine (Stage V)
• Conforms with CE standards, simple and clear operation
• Lifting mixer with low filling height for convenient filling
• Large mixer/hopper for more efficient working
• Fully hydraulic pump and mixer drive with an infinitely variable delivery rate up to 60 l/min
• Lasting value thanks to high resale value
TECHNICAL SPECIFICATIONS
Feed Hopper - 220 l
Mixing Vessel - 180 l
Delivery Rate - 5-60 l/min
Delivery Pressure - 25 bar
Delivery Range - 60 m Horizontal, 40 m Vertical
Compressor - 2-cylinder, 400 l/min, 3.7 bar
Pump - Worm pump 2L6
Engine - Diesel 3-cylinder Kubota, 16.3 kW at 2,600 rpm (Stage V)
Weight - 750 kg
Length x Width x Height - 3260 x 1420 x 1160 mm
Filling height - 800 mm
Max. Aggregate Size - 6 mm
* All data provided is based on experience and depends on the material used. Specifications subject to change without prior notice, no responsibility is taken for the correctness of this information. Other data can be obtained on request.
